PD Series – Mains Power Distributor

We regard our Mains Power Distributors as the consequent final step in optimizing the connection between your audio system and the mains. Using real metallurgically welded connections instead of conventional plugs and sockets, it delivers uncompromised electrical conductivity and a perfect star grounding of your whole audio system.

Advantages

The PD Series Mains Power Distributor is available with four (PD-01) or three (PD-02) outputs and is built around real metallurgically welded in- and outbound cable connections. This uncompromising approach delivers the highest possible electrical conductivity while ensuring a permanently corrosion-resistant connection.

True star grounding across your entire audio system, combined with equal cable lengths, minimizes differences in electrical potential and sound-degrading compensating currents. The unit is fully encased in epoxy resin for effective vibration damping and features a 3 m input cable and 1.80 m output cables. Developed and manufactured in Switzerland, the PD Series is CE certified and designed for maximum reliability and uncompromised sonic performance.

Technical Specifications

Models: PD Series - PD-01 / PD-02 / PD-03

Type: Mains Power Distributor

No. of Outputs: 3 (PD-01), 4 (PD-02), 5 (PD-03)

Cable Length Outputs: 1.8 m, terminated with IEC C13 connectors

Cable Length Inputs: 3 m, terminated with country specific mains plug

Voltage Rating: 100 - 250 V~ 50/60 Hz

Max. Power Rating: 2‘500 W

Dimensions: 22 (W) × 11 (D) × 4.5 (H) cm

Weight: 1.1 kg per unit

Finish: Epoxy potted in ABS enclosure, aluminum
top plate, glass-bead blasted and anodized

Pricing

Sales Price Switzerland (incl. 8.1% VAT)

–

PD Series - PD-01 with 3 Outputs
CHF 850

–

PD Series - PD-02 with 4 Outputs
CHF 950

_

PD Series - PD-03 with 5 Outputs
CHF 1050
